Temp and Humidity Sensor (EU)
3-Series Temp and Humidity Sensor (EU)
By detecting changes in in-home temperature and humidity, the Centralite Temperature and Humidity Sensor can add a whole range of climate control features to your connected home. By reporting these changes in climate, your HVAC system can respond to your comfort level and help reduce wasted energy.
Keep the perfect temperature in the right room.
Most home thermostats are located in the hallways, kitchens, or living rooms. The problem is that we don’t always spend all of our time there. This causes hot and cold spots throughout the house.
Trigger the A/C to turn on when humidity temp levels Increase.
Many smart homes are predisposed to mold and mildew issues. Mold and mildew formation is a perennial concern for homes in humid areas or with a wet basement.
Get an alert when your HVAC system isn’t running correctly.
By monitoring the temperature in different areas of the home, your connected home can notify you if there are problems with your unit. The unit not being able to keep up or having longer run times are both signs that your unit may be having problems.
Humidity Sensor Easy to Mounting Options
The Centralite 3-series Temperature and Humidity Sensor applications can be installed using either adhesive strips or mounting screws (both included). The easy-to-install mounting plate attaches with a single screw, and the sensor simply slides into place on the mount.
Pull-to-pair join process
All 3-series humidity sensor circuits feature “pull-to-pair” joining. The device ships with the battery pre-installed, and all that is needed to begin the joining process is to pull out a small plastic tab from the bottom of the device. There is nothing for the user to take apart or put back together.
Home Automation 1.2 Compatibility
The Temperature and Humidity Sensor is fully ZigBee HA 1.2 certified and is guaranteed to function with all open, ZigBee HA 1.2-certified hubs and devices.
Superior Range and Adaptability
The Centralite Humidity sensor also supports over-the-air updates, providing for seamless upgrades and feature additions without the need for any user interaction.
Temperature Doesn’t Tell the Entire Story
Find your true “comfort level.”
Save Energy and Money with a Temperature and Humidity sensor
By adding advanced climate control features, The Temperature and humidity sensor Eu can help reduce energy costs. By giving your connected smart home automation more insight into how its rooms are being heated and cooled, your HVAC system can work smarter, not harder.
Troubleshooting
Step 1: Remove and replace the device’s battery
Slide the sensor of the mount and remove the cover. Remove the battery and replace it with a new CR-2 battery. Assemble and test the operation.
Step 2: Factory Reset and Rejoin
Slide the sensor off the mount, remove the cover, and remove the battery. While holding down the reset button, reinsert the battery to factory reset the device. Repeat the “Getting Started” steps to rejoin the Zigbee network.
Related Resources
3-Series Temp and Humidity Sensor (EU)
By detecting changes in in-home temperature and humidity, the Centralite Temperature and Humidity Sensor can add a whole range of climate control features to your connected home. By reporting these changes in climate, your HVAC system can respond to your comfort level and help reduce wasted energy.
Keep the perfect temperature in the right room.
Most home thermostats are located in the hallways, kitchens, or living rooms. The problem is that we don’t always spend all of our time there. This causes hot and cold spots throughout the house.
Trigger the A/C to turn on when humidity temp levels Increase.
Many smart homes are predisposed to mold and mildew issues. Mold and mildew formation is a perennial concern for homes in humid areas or with a wet basement.
Get an alert when your HVAC system isn’t running correctly.
By monitoring the temperature in different areas of the home, your connected home can notify you if there are problems with your unit. The unit not being able to keep up or having longer run times are both signs that your unit may be having problems.
Humidity Sensor Easy to Mounting Options
The Centralite 3-series Temperature and Humidity Sensor applications can be installed using either adhesive strips or mounting screws (both included). The easy-to-install mounting plate attaches with a single screw, and the sensor simply slides into place on the mount.
Pull-to-pair join process
All 3-series humidity sensor circuits feature “pull-to-pair” joining. The device ships with the battery pre-installed, and all that is needed to begin the joining process is to pull out a small plastic tab from the bottom of the device. There is nothing for the user to take apart or put back together.
Home Automation 1.2 Compatibility
The Temperature and Humidity Sensor is fully ZigBee HA 1.2 certified and is guaranteed to function with all open, ZigBee HA 1.2-certified hubs and devices.
Superior Range and Adaptability
The Centralite Temperature sensor also supports over-the-air updates, providing for seamless upgrades and feature additions without the need for any user interaction.
Temperature Doesn’t Tell the Entire Story
Find your true “comfort level.”
Save Energy and Money with a Temperature and Humidity sensor
By adding advanced climate control features, The Temperature and humidity sensor can help reduce energy costs. By giving your connected smart home automation more insight into how its rooms are being heated and cooled, your HVAC system can work smarter, not harder.
Troubleshooting
Step 1: Remove and replace the device’s battery
Slide the sensor off the mount and remove the cover. Remove the battery and replace it with a new CR-2 battery. Reassemble and test the operation.
step 2: Factory Reset and Rejoin
Slide the sensor off the mount, remove the cover, and remove the battery. While holding down the reset button, reinsert the battery to factory reset the device. Repeat the “Getting Started” steps to rejoin the Zigbee network.
Related Resources
Temerature and Humidity Sensor Specifications
Dimensions
Wireless
ZigBee Home Automation 1.2
Power
CR-2 Battery
Compatibility
The 3-Series Temp & Humidity Sensor is Compatible with All ZigBee HA 1.2 Platforms*
The Temp and Humidity Sensor has been tested and works with the following platforms:
- SmartThings
- Time Warner IntelligentHome
- Cox Homelife
- Bright House Networks Home Security and Automation
- Rogers Home Monitoring
- PEQ
Environmental
Operating Temperature: 0 to 40°C
Shipping/Storage Temperature: -20 to 50°C
Humidity Range: 0 to 90% R.H. (non-condensing)
Warranty
1-Year Limited Warranty.**
In the Box
- Temp & Humidity Sensor
- Sensor Mount
- CR-2 Battery (pre-installed)
- Installation Guide
- Mounting Screws
- Adhesive Mounting Strips
